Application & Features:
1.Consist of Rack, Milling Cutter, Heating Plate, Hydraulic Station, Control Box, Basket
2.Working Environment must be Between -40~45ºC
3.Pesssure Adjustable Range:0-16 Mpa
4.Max. Temperature of Heating Plate:270 ºC
5.Suitable for PE,PPR,PB,PVDF
Product Number:HD-YY1200 | Including: Rack, Milling Cutter, Heat Plate, Hydraulic Station, Control Box, Basket (Electric Crane and Hoist is Optional) | |||||
Welding Range(mm) | 1000、1100、1200 | |||||
Packing Size(cm) | Wooden Box (1):88*63*65cm, (2):300*1205*190cm,(3):170*115*230cm | |||||
Total Volume | 16.2m³ | Net Weight | 2700KG | Gross Weight | 2980KG | |
Component Name | Rack | Heating Plate | Milling Cutter | Basket | Control Box | Hydraulic Station |
Size(cm) | 295*185*200 | 165*110*225 | 165*110*225 | 117*76*99 | 38*20*43 | 85*60*62 |
Total Power | 28.5kw/380V | |||||
